NEWS for November in the Atom catalog

Hitacs-CUTTING TOOLS EXPERTS has extended the catalog of references compatible with ATOM automated cutting systems.

As a novelty, you will find 3 new oscillating KNIVES and 1 new Circular Knife, all made of Tungsten Carbide and fully compatible with ATOM automated cutting machines.

  • HTA-03596 - Fully compatible with Atom 01043068. 85°/ 65°/ 80° (5°-25°-10°) oscillating knife for cutting soft rubber up to 17 mm thick and minimum radius 2mm.
  • HTA-04736 - Fully compatible with 01040701. 75°/ 87° (0°-15°-3°) oscillating knife for cutting rubber and foam up to 35 mm thick.
  • HTA-45232 - Fully compatible with 01045232. 45°/80° oscillating blade for cutting very rigid materials, non-asbestos materials, leather or reinforced graphite up to 4mm thick and small radii.
  • HTZ-054 - Hard metal Circular Knife  with 28mm Ø compatible for Atom automated cutting machine. Circular knife for single layer cutting, faster cutting speed on soft / smooth textile materials. Similar to Z53 (HTZ-053) knife  but with a bigger diameter of 28 mm.
Knife Atom 01043068
Knife Atom 01040701
Knife Atom 01045232
Knife Atom HTZ-054

NEW

On Atom compatible knives

Atom knife 01043068 / HTA-03596 / compatible for Atom automated cutting machine Atom knife 01043068 / HTA-03596 / compatible for Atom automated cutting machine 2

Atom knife 01043068 / HTA-03596 / compatible for Atom automated cutting machine

03751110000HTA03596
Atom
Equivalent ATOM 01043068 but without tip Atom knife 01043068 / HTA-03596 / compatible for Atom automated cutting machine Description: Knife similar to 01043068 (HTA-43068) but without tip. Knife for cutting soft materials up to 17 mm. Thickness: 0,63 mm. Tools: Electric Oscillating Tool (EOT) and Pneumatic Oscillating Tool (POT).  Composition: Tungsten...
€18.90
Atom blade 01040701 / HV1600 / HTA-04736 / compatible for Atom automated cutting machine Atom blade 01040701 / HV1600 / HTA-04736 / compatible for Atom automated cutting machine 2

Atom blade 01040701 / HV1600 / HTA-04736 / compatible for Atom automated cutting machine

03751110000HTA04736
Atom
Equivalent to 01040701 / HV1600 blade Atom knife 01040701 / HV1600 / HTA-04736 / compatible for Atom automated cutting machine Description: 75°/ 87° (0°-15°-3°) oscillating knife for cutting rubber and foam up to 35 mm thick. Thickness: 1 mm. Tools: Electric Oscillating Tool and Pneumatic Oscillating Tool. Composition: Tungsten Carbide - HM -...
€22.90
Atom knife 01045232 / HTA-45232 / compatible for Atom automated cutting machine Atom knife 01045232 / HTA-45232 / compatible for Atom automated cutting machine 2

Atom knife 01045232 / HTA-45232 / compatible for Atom automated cutting machine

03751110000HTA45232
Atom
Equivalent to ATOM 01045232 Atom knife 01045232 / HTA-45232 / compatible for Atom automated cutting machine Description: 45°/80° oscillating blade for cutting very rigid materials, non-asbestos materials, leather or reinforced graphite up to 4mm thick and small radii. Thickness: 0,63 mm. Tools: Electric Oscillating Tool (EOT) and Pneumatic...
€15.10
